RAM 1500 RHO & TRX
We ordered this RHO November of 24’ and received it in April of 25’. We did extensive fitment and testing of a new GEN2 kit for both RHO & TRX platforms to share. We want to thank Chad and the crew at Morrie’s in Chippewa Falls, WI for all their help!
RHO is Ram’s next generation for aggressive off-road use and has a suspension that performs with the same capabilities as the TRX. Towing an RV, Race Trailer or Boat was definitely not a primary objective! Design modifications to fit both TRX & RHO were required.
There’s 18.25” of full droop travel to account for. We learned a lot over the four + years manufacturing the GEN1 kit. Huge improvements were made to accomodate installation, daily driving, towing and service requirements. As with GEN1, it is easily removable for aggressive off-road use, but will not be required by most owners. The GEN2 kit reduces full compression by only 1.5” as pictures below will show, a vast improvement from the 5.5” of the GEN1. Days of testing were performed to fine tune prototypes into a refined production kit.
Installing the GEN2 kit is faster to install and easily maintained. Testing was done at 3 PSI on rough terrain and found that allows air springs compress to provided ample support from bottoming out. One air fill valve allows pressure to float side-to-side to accommodate greater articulation. This ASAM will provide complete adjustable control, and is a stainless steel bolt-in, no cut, no drill kit!
Any air source from a bike pump to an automatic air management system can be utilized. Please view our "AIR SYSTEMS" page for detailed information. Since introduction, our rugged kits have provided thousands of owners support and confidence while towing. Whatever you do with your truck, this kit will perform the task safely & effectively. Please review our "SAFETY" page.
Our design philosophy is to build them tough with quality components that perform without fail and stand behind every product 100%. Please view our "GENERAL INFO" page for detailed information.
Please "CONTACT US" with any questions.
View of left rear, pulled in 1.5” by the Panhard bar during full extension.
Right side full extension.
Left side full extension.
Taxed with 5,000 lbs. to bottom out the suspension.
View at ride height. Air Springs are rated for 6,000 lbs. of lift and rated @300 PSI
View or right rear, axle pushed out 1.5” by the Panhard bar during full extension.
GEN2 kit triple convoluted air spring at full extension
GEN2 kit triple convoluted air spring at full compression.
GEN2 kit at full compression, note the 1.5” distance from the bump stop to the axle.
View at ride height.
25’ RAM 1500 RHO, A special thanks goes out to Tony at F Bomb Baggers (Joliet, IL) for providing his truck for fitment.
Photo Courtesy of Matt E. from Virginia, 1st TRX Production Kit
Photo Courtesy of Matt E. from Virginia, 1st TRX Production Kit
Photo Courtesy of Jason D. from Parkgate, England UK - Drag Car Hauler
Photo Courtesy of Jason D. from Parkgate, England UK - Drag Car Hauler
Photo Courtesy of Steve W. from Illinois
Photo Courtesy of Steve W. from Illinois
Owner Eric O. of Fallon, NV stopped by the shop for some help.
After a few hours, the 22’ TRX looked as good as the 1948 Power Wagon.
Photo Courtesy Instagram @stilov_cars
Photo Courtesy Instagram @stilov_cars
Photo Courtesy of Mark P. Wellington, New Zealand
Roland J. from MN stopped in with his Hennessey TRX for air springs and air system.
We’re happy it didn’t fall off the lift, it would have crushed insurance limits.
Larry S. from MN stopped in for air springs.
Photo Courtesy of Adam W. Tasmania Australia
Photo Courtesy of Adam W. Tasmania Australia
Photo Courtesy of Arturo M. Madrid, Spain
Photo Courtesy of Jason Y. Utah
Photo Courtesy of Jason Y. Utah
Vitali C. from Toronto, ON Canada stopped in for air springs and air system.
Photo Courtesy of Ronald K. Belgium
Photo Courtesy of Ronald K. Belgium
Photo Courtesy of Ronald K. Belgium
Photo Courtesy of Ronald K. Belgium
Romero S. from Florida made the trip for air springs and air system.
Photo Courtesy of Dave D. OR
John L. from South Dakota dropped by for an install.
John’s 24’ needed a bit of a lift.
After an hour or so, John was riding high again.
